The patterned pipe mentioned here refers to the pipe with patterned pattern on the surface of straight welded pipe, and the method of producing the pipe weld mould of this kind of patterned pipe is also different. The mold of the overall forming process is the same as the conventional pipe weld mould without pattern. It is not introduced here. Our GXG technology focuses on which pipe weld moulds have long been patterned on the surface of the pipe.

The formation of pattern pattern on the surface of pipe is basically two modes. One is to directly press out the pattern on the raw material steel strip with the embossing die, and the other is to install the pattern die on the straightening frame, that is, extrude the pipe after forming. The two are suitable for the production of pipes with different types of patterns. The specific process to be adopted should be determined in combination with the pattern style of the pipe.

Our GXG technology still has some technical experience in the design of pattern TUBE pipe weld mould. If you also want to produce pattern pipe, you might as well contact us to try to achieve the effect you want and still have the ability to meet it.

Key words:pipe weld mould
